SeGMo-Box GEL 65Mx
Intelligent connection box in modular design
- Two housing variants with 4/9 slots available
- Module combination for controlling up to 17 positioning drives or up to 48 position displays
- Mixed operation of positioning drives and position displays possible
- Conveniently configurable via SeGMo-Support Tool
- Separate network connection for Industrie 4.0 applications
- Web visualization
Product details
| Technical data | GEL 65Mx | |
|---|---|---|
| Supply voltage | 24 ... 30 V DC, central supply for logic up to 4A, local supply for power per channel up to 5A | |
| Temperature range | 0 °C to 60 °C | |
| Protection class | IP 20 | |
| Dimensions W x H x L in mm | 194 x 197 x 163.6 (280.6) mm | |
| Material | galvanized | |
| Interface | Sercos III; POWERLINK; PROFINET IO / RT; EtherCAT; EtherNet/IP | |
| Mounting | optional top-hat rail mounting or screwable via mounting bracket | |
| Optional | Web Server | |
Corresponding products and solutions
Stp-files
If you need stp data, then send an e-mail with the article no. to info@lenord.de.
